Triple R Lighting Can-Am Maverick R Hood Mount Kit
SKU: TR-VIFK-MAVR-01K-US-LINEAR-6ELITE-2PIN
1 10

Triple R Lighting Can-Am Maverick R Hood Mount Kit

SKU: TR-VIFK-MAVR-01K-US-LINEAR-6ELITE-2PIN
$345.00
Custom Icon
Earn $6 Fueled Cash
This item ships FREE

Triple R Lightning Can-Am Maverick R Hood Mount Kit



Designed and manufactured by one the leading suppliers of metal works parts for the side-by-side market based in the US, Triple-R Lights is delighted to offer the Can-Am Maverick R Hood Mount Kit. Compatible with our Linear-6 high performance LED lights, the kit facilitates the installation of the Linear-6 in the hood scoop for a stealth install that comes alive at night! The Linear-6 is available in Elite, Elite Yellow or Elite+ grade which boasts white and yellow LEDs to be used independently or in combination – perfect when navigating tricky off-road conditions.

The mounting bracket itself is made from 3mm mild steel, with satin black powder coat, and supplied complete with fixtures. The mounts locate into original fixing locations on the Maverick R’s hood, resulting in a clean, robust install guaranteed to last and impress.



Features:
  • Produced from 3mm mild steel with satin black powder coat finish
  • Supplied with stainless steel fasteners
  • Locates in original fixing locations on the Can-Am Maverick R
  • Designed for Linear-6 high performance LED lights
  • Designed & manufactured in the USA



Technical Specifications:

Linear-6
Elite Yellow

 Linear-6 Elite Linear-6 Elite+
(Boost / Low Output Mode)
Voltage Range (DC) 10-32V 10-32V 10-32V
LED Life 50,000 hrs 50,000 hrs 50,000 hours
Weight 1.1 lbs 1.1 lbs 1.1 lbs
HIGH BEAM FUNCTION
Total Luminous Flux 4,320 Lm 4050 Lm 5100 / 2500 Lm
Total Driver 'FOV' Flux † 2,839 Lm 2884 Lm 3645 / 1822 Lm
Colour Temperature PC Yellow 5000K 5000K
Number of High Output LEDs 12 12 12
Power Consumption 42 Watts 42 Watts 48 W / 24 W
Current Draw (at 14.4V) 2.9 Amps 2.9 Amps 3.6 A / 1.8 A
PHOTOMETRIC DATA
Horizontal Beam Angle 80˚ 64o 84o
0.25 lx Line 536m 563 m 600m / 424m
0.5 lx Line 379m 398 m 424m /300m
1 lx Line 268m 282 m 300m / 212m
3 lx Line 155m 163 m 173m / 122m

† Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45o left/right, and +/- 10o up/down. For more information – click here.



What's Included:
  • x1 Hood Mount U-Bracket
  • x2 Fasteners



Instructions:
Video Instructions:
