Superwinch 7500 LBS 12V DC 5/16in x 54ft Synthetic Rope S7500 Winch
SKU: TN-1475201
1 6

Superwinch 7500 LBS 12V DC 5/16in x 54ft Synthetic Rope S7500 Winch

SKU: TN-1475201
$786.45
Custom Icon
Earn $15 Fueled Cash
This item ships FREE

Superwinch 7500 LBS 12V DC 5/16in x 54ft Synthetic Rope S7500 Winch

The S7500SR Winch continues Superwinch's dominance as the leader in trailer-specific winching. The Superwinch S7500SR easily pulls loads up to 7,500 lbs, powered by a stout 3.6 HP permanent-magnet motor and an all-steel 3-stage planetary gearbox. The S7500SR includes a safety-tinted protective cover for operator safety, and to protect the cable and drum. The machined aluminum free-spool lever can also be easily operated by foot.

Features:
  • 12V DC 7,500 lbs rated line pull
  • 3.6 HP permanent magnet motor provides dynamic braking
  • 3-Stage planetary gearing with 249:1 ratio
  • Sealed solenoid
  • Lever style freespool allows hand or foot operation
  • Steel cut gears for better engagement and longevity
  • 5/16 in x 54 ft synthetic rope
  • Automatic load holding brake
  • Stainless steel 2-way roller fairlead

Instructions:

Specifications:

Brake Mechanical, Automatic
Clutch
N/A
Dimensions N/A
Drum Diameter N/A
Drum Length N/A
Fairlead 2-way Roller/Hawse hybrid
Gear Ratio 249:1
Gearing 3-Stage Planetary
Height 0
Hook
Heavy-Duty, Clevis Pinned Latched
Installed Weight 92 lbs (42 kg)
Length 0
Line Pull, 0 lbs 80 Amps Motor Draw/19 FPM (5.8 MPM) Line Speed
Line Pull, 5,500 lbs 410 Amps Motor Draw/2 FPM (0.6MPM) Line Speed
Motor 3.6 HP Permanent Magnet
Mounting Bolt Pattern N/A
Rated Line Pull 7,500 lbs (3401.9 kg)
Remote 30.5 handheld
Rope Synthetic 3/8in x 92ft (9.5mm x 28.04m)
Solenoid Sealed S3 Solenoid
Warranty 2 Year Limited
Weight 0
Width 0
