CageWRX '22+ Polaris RZR Pro R 4 Baja Spec Roll Cage Kit

CageWRX '22+ Polaris RZR Pro R 4 Baja Spec Roll Cage Kit

High quality DOM steel used throughout. Main tubes (roof tube and B-Pillar) are 1.75" diameter .120" wall thickness, rear intrusion tubes are 1.5" diameter .095" wall thickness, front intrusion tubes are 1.25" diameter .095" wall thickness, all remaining tubes are 1.75" diameter .095" wall thickness. Our "Baja Spec" roll cages use all stock mounting locations. Trophy Truck inspired design provides exceptional safety for driver and co-rider. This is truly the best roll cage kit on the market. All tubes are mandrel bent and laser cut for exact fit. No grinding or other work required. Kit can be assembled and welded on chassis without the need for a separate fixture.

Kit Includes:

• 20 Laser Notched Tubes with tab and slot design for easy positioning of tubes

• 8 Billet Tube Ends (chassis clamps)

• 2 Weld On C-Pillar Body Brackets

• 2 Weld On Bed Mounting Brackets

Instructions:

• CW4SPROR-FT.PDF
